AOP: 296

Title

A descriptive phrase which references both the Molecular Initiating Event and Adverse Outcome.It should take the form “MIE leading to AO”. For example, “Aromatase inhibition leading to reproductive dysfunction” where Aromatase inhibition is the MIE and reproductive dysfunction the AO. In cases where the MIE is unknown or undefined, the earliest known KE in the chain (i.e., furthest upstream) should be used in lieu of the MIE and it should be made clear that the stated event is a KE and not the MIE.  More help

Oxidative DNA damage leading to chromosomal aberrations and mutations

Short name
A name that succinctly summarises the information from the title. This name should not exceed 90 characters. More help
Oxidative DNA damage, chromosomal aberrations and mutations

Graphical Representation

A graphical representation of the AOP.This graphic should list all KEs in sequence, including the MIE (if known) and AO, and the pair-wise relationships (links or KERs) between those KEs. More help
Click to download graphical representation template Explore AOP in a Third Party Tool

Authors

The names and affiliations of the individual(s)/organisation(s) that created/developed the AOP. More help

Eunnara Cho1,2, Ashley Allemang3, Marc Audebert4, Vinita Chauhan5, Stephen Dertinger6, Giel Hendriks7, Mirjam Luijten8, Francesco Marchetti1,2, Sheroy Minocherhomji9, Stefan Pfuhler3, Daniel J. Roberts10, Kristina Trenz11, Carole L. Yauk2, 12 *

1 Environmental Health Science and Research Bureau, Health Canada, Ottawa, ON, Canada

2 Department of Biology, Carleton University, Ottawa, ON, Canada

3 The Procter & Gamble Company, Mason, OH, United States

4 Toxalim, INRAE, Toulouse, France

Consumer and Clinical Radiation Protection Bureau, Health Canada, Ottawa, ON, Canada

Litron Laboratories, Rochester, NY, United States

7 Toxys, Leiden, The Netherlands

Centre for Health Protection, National Institute for Public Health and the Environment (RIVM), Bilthoven, the Netherlands

Amgen, Thousand Oaks, CA, United States

10 Charles River Laboratories, Skokie, IL, United States

11 Boehringer-Ingelheim, Ingelheim, Germany

12 Department of Biology, University of Ottawa, Ottawa, ON, Canada

*Corresponding author: Carole Yauk (carole.yauk@uottawa.ca)

Point of Contact

The user responsible for managing the AOP entry in the AOP-KB and controlling write access to the page by defining the contributors as described in the next section.   More help
Carole Yauk   (email point of contact)

Contributors

Users with write access to the AOP page.  Entries in this field are controlled by the Point of Contact. More help
  • Carole Yauk

Coaches

This field is used to identify coaches who supported the development of the AOP.Each coach selected must be a registered author. More help
  • Jason M. O'Brien

Status

Provides users with information concerning how actively the AOP page is being developed, what type of use or input the authors feel comfortable with given the current level of development, and whether it is part of the OECD AOP Development Workplan and has been reviewed and/or endorsed. OECD Status - Tracks the level of review/endorsement the AOP has been subjected to. OECD Project Number - Project number is designated and updated by the OECD. SAAOP Status - Status managed and updated by SAAOP curators. More help
Handbook Version OECD status OECD project
v2.0 WPHA/WNT Endorsed 1.76
This AOP was last modified on April 29, 2023 16:03

Revision dates for related pages

Page Revision Date/Time
Increase, Oxidative damage to DNA March 08, 2024 11:58
Inadequate DNA repair March 08, 2024 12:15
Increase, DNA strand breaks March 08, 2024 12:05
Increase, Mutations May 15, 2023 08:47
Increase, Chromosomal aberrations March 08, 2024 12:20
Increase, Oxidative DNA damage leads to Inadequate DNA repair March 08, 2024 14:48
Increase, Oxidative DNA damage leads to Increase, DNA strand breaks March 08, 2024 15:19
Inadequate DNA repair leads to Increase, DNA strand breaks January 09, 2023 20:56
Increase, Oxidative DNA damage leads to Increase, Mutations January 09, 2023 21:04
Increase, DNA strand breaks leads to Inadequate DNA repair March 08, 2024 14:56
Increase, DNA strand breaks leads to Increase, Mutations January 09, 2023 21:05
Inadequate DNA repair leads to Increase, Mutations March 08, 2024 15:00
Inadequate DNA repair leads to Increase, Chromosomal aberrations March 08, 2024 15:05
Increase, DNA strand breaks leads to Increase, Chromosomal aberrations January 09, 2023 21:05
Hydrogen peroxide May 19, 2019 17:21
Potassium bromate May 19, 2019 17:21
Ionizing Radiation May 07, 2019 12:12
Cadmium chloride May 19, 2019 17:23
tert-Butyl hydroperoxide May 19, 2019 17:24
Reactive oxygen species August 15, 2017 10:43
Hydroquinone November 08, 2019 13:06
4-Nitroquinoline 1-oxide November 08, 2019 13:07

Abstract

A concise and informative summation of the AOP under development that can stand-alone from the AOP page. The aim is to capture the highlights of the AOP and its potential scientific and regulatory relevance. More help

This AOP network describes the linkage between oxidative DNA damage and irreversible genomic damage (chromosomal aberrations and mutations). Both endpoints are of regulatory interest because irreversible genomic damage is associated with various adverse health effects such as cancer and heritable disorders.

Mutagens are genotoxic substances that alter the DNA sequence and this includes single base substitutions, deletion or addition of a single base or multiple bases of DNA, and complex multi-site mutations. Mutations can occur in coding and non-coding regions of the genome and can be functional or silent. The site and type of mutation will determine its consequence. Clastogens are genotoxic substances that cause DNA single- and double-strand breaks that can result in deletion, addition, or rearrangement of sections in the chromosomes. As with mutagens, the type and extent of chromosome modification(s) determine cellular consequences.

The molecular initiating event (MIE) of this AOP is increase in oxidative DNA damage, indicated by increases in oxidative DNA lesions. DNA in any cell type is susceptible to oxidative damage due to endogenous (e.g., aerobic respiration) and exogenous (i.e., exposure to oxidants) oxidative insults. Although this is the MIE for this AOP network, we note that there are numerous upstream key events (KE) that can also lead to DNA oxidation. Thus, we expect this AOP to be expanded upstream, and to be incorporated into a variety of AOP networks. Generally, cells are able to tolerate and readily repair oxidative DNA lesions by basal repair mechanisms. However, excessive damage can override the basal repair capacity and lead to inadequate repair of oxidative damage (KE1). Mutations (AO1) can arise from incorrect repair following oxidative damage (KE1), where incorrect bases are inserted opposite lesions during DNA replication. Insufficiently or incompletely repaired oxidative DNA lesions can also lead to DNA strand breaks (KE2) that, if insufficiently repaired (KE1), may result in chromosome aberrations (AO2) and/or mutations (AO1) following DNA replication.

Support for this AOP is strong based on extensive understanding of the mechanisms involved in this pathway, evidence of essentiality of certain KE (i.e., studies using reactive oxidative species scavengers and modulating DNA repair enzymes), and a robust set of studies providing empirical support for many of the KERs.

We anticipate that this AOP will be of widespread use to the regulatory community as oxidative DNA damage is considered an important contributor to the adverse health effects of many environmental toxicants. Importantly, the AOP points to critical research gaps required to establish the quantitative associations and modulating factors that connect KEs across the AOP, and highlights the utility of novel test methods in understanding and evaluating the implications of oxidative DNA damage.

AOP Development Strategy

Context

Used to provide background information for AOP reviewers and users that is considered helpful in understanding the biology underlying the AOP and the motivation for its development.The background should NOT provide an overview of the AOP, its KEs or KERs, which are captured in more detail below. More help

This AOP network describes oxidative damage to DNA (MIE) leading to mutations (AO1) and chromosomal aberrations (AO2). The AOP summarizes the evidence supporting how increases in oxidative DNA lesions can overwhelm DNA repair mechanisms, causing an accumulation of unrepaired lesions and/or repair intermediates. Failure to resolve oxidative DNA damage can lead to permanent alterations to the genome. Increases in reactive oxygen and nitrogen species (RONS) that can lead to oxidative DNA lesions is a broad characteristic of many xenobiotics and indeed, is noted as one of the 'key characteristics of carcinogens' (Smith et al., 2016). Moreover, oxidative stress is often suspected to be the cause of DNA damage by substances whose mechanism of genotoxicity is uncertain [e.g., glyphosate (Kier and Kirkland, 2013; Benbrook, 2019), monosodium glutamate (Ataseven et al., 2016)]. Thus, this AOP network will serve as a key tool in mechanism-based genotoxic hazard identification and assessment.

Oxidative stress describes an imbalance of oxidants and antioxidants in the cell. Oxidative stress can occur when free radicals overwhelm the antioxidant capacity under certain physiological conditions, such as inflammation due to diseases, and also through exogenous stressors that are oxidants and/or induce ROS and other free radicals. Excess oxidants can occur following exposure to agents that: (a) generate free radicals and other RONS, (b) deplete cellular antioxidants, and/or (c) have oxidizing properties (Parke, 1982). Furthermore, there are substances that can induce inflammatory responses and in turn cause oxidative stress as a secondary effect (Gustafson et al., 2016). The effects of oxidative stress in the cell are broad; all biomolecules are susceptible to damage by oxidizing agents. Oxidative stress and associated damage to cellular components have been implicated in various diseases, including neurodegenerative diseases, cardiovascular diseases, diabetes, and different cancers (Liguori et al., 2018).

Free radicals and other RONS are continuously generated as by-products of endogenous redox reactions (e.g., oxidative phosphorylation in the mitochondria, NADPH oxidation to NADP+ by NADPH oxidase) at steady state. The steady state concentration of oxidants is essential for cellular functions (e.g., as secondary signalling molecules) and is tightly regulated by endogenous antioxidants such as glutathione, and antioxidant enzymes such as superoxide dismutase and catalase. There are many protective barriers against oxidative damage to the genome within the cell. Compartmentalization is one of the ways in which DNA is protected from exposure to ROS and other free radicals generated by various biological processes that occur in different parts of the cell. Examples include CYP450 enzyme activity in the cytoplasmic endoplasmic reticulum and oxidative phosphorylation in the mitochondria (Dan Dunn et al., 2015; Veith and Moorthy, 2019).

Exogenous sources such as ionizing radiation, ultraviolet (UV) radiation, and certain compounds can directly or indirectly generate reactive species, causing oxidative stress. Oxidizing compounds can also directly cause oxidative damage to cellular components (Liguori et al., 2018). The nitrogenous bases of the DNA are susceptible to oxidation by both endogenous and exogenous oxidants (Berquist and Wilson III, 2012). Oxidizing agents cause a wide range of oxidative DNA lesions. In addition to strand breaks due to direct RONS attack on the phosphate backbone, the nitrogenous bases can be modified in various ways by free radicals and other reactive species. If these lesions are left unrepaired or the attempt at repair fails, mutations and strand breaks can occur, permanently altering the DNA sequence. All nitrogenous bases are susceptible to oxidative damage, however, to different extents. A variety of DNA lesions caused by RONS are described within this AOP (Cooke et al., 2003). Notably, guanine is most readily damaged by RONS and other oxidants due to its low reduction potential. Indeed, 8-oxoG is the most abundant oxidative DNA lesion and has been extensively studied. Consequently, chromosomal regions containing a higher GC content are more susceptible to oxidative base modifications. For example, human telomeres, which are constituted by TTAGGG repeats and a single-stranded G-rich 3' overhang, are known to be comparatively more sensitive to oxidative damage than other regions in the genome and accumulate 8-oxodG lesions that eventually lead to telomere shortening and genomic instability (Petersen et al., 1998; Bolzan, 2012; Fouquerel et al., 2019). The repair mechanisms and consequences of oxidative damage to telomeres are active areas of research.

Within this AOP network, we mainly focus on 8-oxo-dG as oxidative DNA damage representing the MIE, for practicality. The fate of guanine lesions has been most extensively researched and well understood (Roszkowski et al., 2011; Whitaker et al., 2017; Cadet et al., 2017; Markkanen, 2017). Also, 8-oxodG is an accepted biomarker of oxidative stress and oxidative damage to DNA both in vitro and in vivo (Cooke et al., 2008; Roszkowski et al., 2011; P. Li et al., 2014; Guo et al., 2017). Several different detection methods for 8-oxo-dG are commercially available and, thus, are easy to access (e.g., immunodetection, comet assay). We note that 8-oxo-dG is not a terminal product of oxidative damage; 8-oxo-dG can be further oxidized to additional mutagenic lesions such as spiroiminodihydantoin and guanidinohydantoin (Jena and Mishra, 2012). However, as with many other oxidative lesions on pyrimidines and adenine, these guanine lesions are estimated to be small fractions compared to 8-oxo-dG (Yu et al., 2005; Cooke et al., 2008).

The pathway to mutations (AO1) from oxidative DNA lesions can either proceed (a) directly to mutation through replication of unrepaired oxidized DNA bases (insertion of an incorrect nucleotide by a replicative or translesion polymerase), or (b) indirectly through the creation of strand breaks that can be misrepaired to introduce mutations (Taggart et al., 2014; Rodgers and McVey, 2016). Strand breaks can arise during attempted repair of oxidative DNA lesions. Oxidative base damage is predominantly repaired by base excision repair (BER), and by nucleotide excision repair (NER) to a lesser extent (Whitaker et al., 2017). In the excision repair pathways, single strand breaks (SSB) are transiently introduced as repair intermediates. With increasing oxidative lesions and more lesions in close proximity to each other, the quality and efficiency of repair may be compromised, resulting in persistent unrepaired lesions and repair intermediates. Accumulated repair intermediates such as SSBs, oxidized bases, and abasic sites can interfere with proximal excision repair and/or impede replication fork elongation, leading to double strand breaks (DSBs), which are more toxic and difficult to repair (Yang et al., 2006; Sedletska et al., 2013; Ensminger et al., 2014). Furthermore, if a SSB is introduced nearby another SSB on the opposite strand prior to or during excision repair, these SSBs may be converted to DSBs. Some studies suggest that multiple DNA lesions within one or two helical turns can increase the rate of DSB formation (Cannan and Pederson, 2017). Insufficiently repaired DSBs (incorrect or lack of rejoining) can permanently alter the DNA sequence (e.g., insertion, deletion, translocations), and cause both mutations (AO1) and structural chromosomal aberrations (AO2) (Rodgers and McVey, 2016). These processes are described in more detail within the AOP.

Overall, we anticipate that this AOP network will provide a key sub-network that will be relevant to many future AOPs. However, we note that the AOs herein, increased mutations and chromosomal aberrations, are regulatory endpoints of concern in and of themselves. This AOP also provides a template for designing testing strategies for RONS-induced genetic effects. Despite the fact that this is a long-studied area in genetic toxicology, this work highlights notable gaps in the empirical evidence linking adjacent KEs. For example, the extent to which the levels of oxidative DNA damage must increase before DNA repair processes are overwhelmed leading to an AO is currently poorly understood, and may vary based on the test system. Hence, further data are needed to improve our ability to predict whether this pathway is relevant to a chemical’s toxicological effects..

Strategy

Provides a description of the approaches to the identification, screening and quality assessment of the data relevant to identification of the key events and key event relationships included in the AOP or AOP network.This information is important as a basis to support the objective/envisaged application of the AOP by the regulatory community and to facilitate the reuse of its components.  Suggested content includes a rationale for and description of the scope and focus of the data search and identification strategy/ies including the nature of preliminary scoping and/or expert input, the overall literature screening strategy and more focused literature surveys to identify additional information (including e.g., key search terms, databases and time period searched, any tools used). More help

Summary of the AOP

This section is for information that describes the overall AOP.The information described in section 1 is entered on the upper portion of an AOP page within the AOP-Wiki. This is where some background information may be provided, the structure of the AOP is described, and the KEs and KERs are listed. More help

Events:

Molecular Initiating Events (MIE)
An MIE is a specialised KE that represents the beginning (point of interaction between a prototypical stressor and the biological system) of an AOP. More help
Key Events (KE)
A measurable event within a specific biological level of organisation. More help
Adverse Outcomes (AO)
An AO is a specialized KE that represents the end (an adverse outcome of regulatory significance) of an AOP. More help
Type Event ID Title Short name
MIE 1634 Increase, Oxidative damage to DNA Increase, Oxidative DNA damage
KE 155 Inadequate DNA repair Inadequate DNA repair
KE 1635 Increase, DNA strand breaks Increase, DNA strand breaks
AO 185 Increase, Mutations Increase, Mutations
AO 1636 Increase, Chromosomal aberrations Increase, Chromosomal aberrations

Relationships Between Two Key Events (Including MIEs and AOs)

This table summarizes all of the KERs of the AOP and is populated in the AOP-Wiki as KERs are added to the AOP.Each table entry acts as a link to the individual KER description page. More help

Network View

This network graphic is automatically generated based on the information provided in the MIE(s), KEs, AO(s), KERs and Weight of Evidence (WoE) summary tables. The width of the edges representing the KERs is determined by its WoE confidence level, with thicker lines representing higher degrees of confidence. This network view also shows which KEs are shared with other AOPs. More help

Prototypical Stressors

A structured data field that can be used to identify one or more “prototypical” stressors that act through this AOP. Prototypical stressors are stressors for which responses at multiple key events have been well documented. More help

Life Stage Applicability

The life stage for which the AOP is known to be applicable. More help
Life stage Evidence
All life stages

Taxonomic Applicability

Latin or common names of a species or broader taxonomic grouping (e.g., class, order, family) can be selected.In many cases, individual species identified in these structured fields will be those for which the strongest evidence used in constructing the AOP was available. More help
Term Scientific Term Evidence Link
human Homo sapiens NCBI
mice Mus sp. NCBI
rat Rattus norvegicus NCBI
fish fish NCBI

Sex Applicability

The sex for which the AOP is known to be applicable. More help
Sex Evidence
Unspecific

Overall Assessment of the AOP

Addressess the relevant biological domain of applicability (i.e., in terms of taxa, sex, life stage, etc.) and Weight of Evidence (WoE) for the overall AOP as a basis to consider appropriate regulatory application (e.g., priority setting, testing strategies or risk assessment). More help

Biological plausibility:

Overall, the biological plausibility of this AOP network is strong. This network was developed by a team of experts within the Health and Environmental Sciences Institute’s Genetic Toxicology Technical Committee who have decades of experience in research on DNA repair and genetic toxicology.

Oxidative DNA lesions are primarily repaired by base excision repair (BER). BER is a multistep process that involves multiple enzymes including OGG1, which removes oxidized guanine bases and creates a nick 3’ to the damaged base, and APE1, which then removes the resulting abasic site by cleaving 5’ to the damaged base. It is known that BER glycosylases are constitutively expressed and that APE1 is an abundant enzyme (Tell et al., 2009). A spike in BER substrates could lead to an imbalance in the initiating steps of BER, causing an accumulation of abasic sites and other repair intermediates (e.g., SSBs) that can lead to the AOs described herein (Coquerelle et al., 1995; Yang et al., 2006; Nemec et al., 2010). Another suspected and biologically plausible mechanism by which oxidative DNA lesions can lead to clastogenic effects is through futile cycles of MUTY-initiated BER, which removes dA inserted opposite 8-oxodG during replication. MUTYH is readily available at the replication foci to initiate BER if needed but can initiate BER post-replication as well (Hayashi et al., 2002; Nakamura et al., 2021). During BER, following the removal of dA by MUTY and APE1, polymerases such as pol β and pol κ could re-insert dA opposite 8-oxodG, rendering the repair process futile. Such cyclical rounds of BER may cause an accumulation of repair intermediates such as SSBs in the newly synthesized strand (Hashimoto et al., 2004; Oka and Nakabeppu, 2011) SSBs can turn into DSBs if they occur in close proximity to each other on opposite strands (Iliakis et al., 2004; Fujita et al., 2013; Mehta and Haber, 2014). If DSBs are not repaired in a timely manner, the broken ends may diffuse away from their original position and result in genetic translocation where incorrect ends are joined, or loss of DNA segments, leading to structural aberrations (AO2) (Obe et al., 2010; Durante et al., 2013).

Error-prone repair of DSBs (KE1 Description section 3) can also lead to mutations, providing an alternate pathway to AO1, an increase in mutations (Sedletska et al., 2013). Non-homologous end joining (NHEJ), the error-prone joining of two broken ends, is a faster process compared to homologous recombination (HR), which uses the homologous sequence in the sister chromatid or homologous chromosome as a template to ensure fidelity of the reconstructed strands (Mao et al., 2008a; Mao et al., 2008b). The preference for the use of sister chromatids versus homologous chromosomes in HR depends on the stage of cell cycle in which the DSB occurs. NHEJ may be preferred over HR in many instances, especially under stress, leading to altered sequences at the site of repair (Rodgers and McVey, 2016). HR is mostly restricted to S and G2 phases of the cell cycle and, while NHEJ can occur at all stages of the cell cycle, it mostly occurs in G1, when the sister chromatids have not yet been synthesized (Brandsma and van Gent, 2012).

The structure of the site of a DSB and end resection can determine the repair pathway and the repair outcome. Typically, breaks with single stranded overhangs are processed by end resection and proceed to HR or error-prone homology-based annealing (i.e, single strand annealing and alternative end-joining). DSBs with blunt ends are more likely to be rejoined by NHEJ (Ceccaldi et al., 2016). The error-prone nature of DSB repair by NHEJ has been extensively studied and widely accepted. Under stress by exogenous or endogenous sources (e.g., xenobiotics), DSBs can also lead to mutagenic salvage DNA repair pathways such as break-induced replication (BIR) and microhomology-mediated break-induced replication (MMBIR) which are linked to mutagenesis, chromosomal rearrangemnts, and genomic instability (Sakofsky et al., 2015; Kramara et al., 2018).

It is established and accepted that unrepaired oxidative DNA lesions, especially 8-oxodG and FapydG, are mutagenic (AO1). During DNA replication, the presence of these unrepaired adducts (KE1: Inadequate repair) on nucleotides leads to incorrect base pairing with incoming nucleosides. This occurs without causing structural disturbance leading to evasion of mismatch repair (Cooke et al., 2003). It is well-understood that both 8-oxodG and FapydG readily base pair with adenine, giving rise to G to T transversions, which are the predominant base substitutions caused by oxidative stress (Cadet and Wagner, 2013; Poetsch et al., 2018)

The underlying biology of the KERs leading to chromosomal aberrations (AO2) is more complex. There are a variety of biologically plausible mechanisms that link inadequate repair of oxidative DNA lesions (KE1; see section 2) of KE Description) to DNA strand breaks (KE2), which, if insufficiently repaired (KE1; see section 3) of KE Description), can cause chromosomal aberrations. Mechanistically, these pathways are well understood (Yang et al., 2006; Nemec et al., 2010; Markkanen, 2017). However, empirical evidence supporting the occurrence of these events is limited in the current literature.

Telomeres, which are rich in GC, are especially susceptible to oxidative damage. 8-oxodG in telomeres causes the replicative DNA polymerase δ to stall because pol δ is not proficient in extending past dC inserted opposite 8-oxodG (Markkanen et al. 2012). Thus, an accumulation of 8-oxodG in telomeres can increase the risk of replication fork collapsing due to stalling (Fouquerel et al. 2019). Furthermore, oxidized dNTPs such as 8-oxoGTPs inserted in the telomere by the telomerase terminates the elongation process as the telomerase is incapable of extending past an 8-oxodG (Fouquerel et al. 2016). Both scenarios can result in the loss and shortening of telomeres. Damage to telomeres can trigger the DNA damage response and be treated in the same manner as DSBs, in which unprotected ends are fused with other available ends leading to structural aberrations (i.e., chromosomal fusions, bridges, micronuclei) (Barnes et al., 2019; Fouquerel et al., 2019).

Time- and dose-response concordance:

The WOE supporting the time- and dose-response concordance of KEs leading to the AOs is between moderate and strong.

The MIE (increase in oxidative DNA lesions) can be measured shortly following exposure to stressors. In cell-free systems and cell-based in vitro models, 8-oxodG has been quantified as early as 15 minutes following chemical exposure (Ballmaier and Epe, 2006). Oxidative lesion formation and induction of strand breaks have been demonstrated by time course experiments, where increases in oxidative lesions were detected at earlier time points and at lower concentrations than strand breaks following exposure to various oxidative stress-inducing chemicals [e.g., Ballmaier and Epe (2006), Deferme et al. (2013)]. Mutations (AO1) and chromosomal aberrations (AO2) must be measured after replication and cell division; therefore, these endpoints are only detected at much later time points than the MIE and KEs. Due to the vastly different sensitivities and dynamic ranges of the methodologies detecting the events in these AOPs, it is difficult to demonstrate concordance in concentration-response between the upstream events and AO.

Uncertainties, inconsistencies, and data gaps:

Currently, quantitative understanding of the amount of oxidative lesions that lead to the two AOs of this AOP network, mutations and chromosomal aberrations, is very limited. Very few studies have specifically investigated the extent of chromosomal aberrations induced by different levels of oxidative DNA lesions. Quantitative studies of different oxidative DNA lesions corresponding to mutation frequencies are also very limited. In order to increase the quantitative understanding of the KERs and to facilitate predictive toxicology, studies are needed to investigate the quantity of 8-oxodG in addition to the endogenous levels required to overwhelm DNA repair and lead to chromosomal aberrations and mutations. We note that the mutagenicity of 8-oxodG has been most extensively studied, while other oxidative DNA lesions have been studied to a lesser extent. In addition, oxidative DNA base modifications such as 8-oxoG also appear to play a role in modulating gene expression and serve as epigenetic markers (Ba and Boldogh, 2018; Bordin et al. 2021). Thus, the interplay of the regulatory roles of oxidized DNA bases and DNA damage response, and its influence on the toxicity of oxidative DNA lesions must be considered.

Quantitative understanding of the relationships comes primarily from studies that modulate levels of oxidative DNA damage through manipulation of repair enzyme activity. In these studies, conflicting observations have been made following modulation of OGG1, the primary repair enzyme for 8-oxodG lesions. While OGG1 protected against DSB formation and cytotoxicity of certain compounds (e.g., methyl mercury, bleomycin, hydrogen peroxide), DSBs were exacerbated by the presence of OGG1 in some other cases (e.g., ionizing radiation, conflicting results for hydrogen peroxide) (Ondovcik et al., 2012; Wang et al., 2018). Available literature indicate that the effect of inadequate repair of oxidative lesions manifests differently for different stressors; it has been suggested that these discrepancies may be due to the difference in proximity of lesions to each other (clustered lesions vs. single lesions) (Yang et al., 2004; Yang et al., 2006).

This AOP network primarily describes oxidative damage to the nuclear DNA (nDNA). However, we must acknowledge that oxidative damage occurs also in the deoxynucleotide triphosphate (dNTP) pool and mitochondrial DNA (mtDNA). Due to mtDNA's location, it is more susceptible to oxidative damage than nDNA. Indeed, crosstalk exists between the nucleus and mitochondria during oxidative stress (Cha et al., 2015; Saki and Prakash, 2017). BER maintains both mitochondrial and nuclear genomic integrity (Cha et al., 2015). Oxidized dNTPs, especially 8-oxodGMP, can be inserted into both genomes during replication and excision repair, resulting in mismatches and impediment of the repair of existing damage, respectively; both scenarios can directly lead to inadequate DNA repair, contributing to the progression of the AOP network (Colussi et al., 2002; Russo et al., 2004; Caglayan et al., 2017). Moving forward, KEs addressing oxidative damage to the dNTP pool and mtDNA are necessary to build a more complete map of oxidative stress-related genotoxicity and to expand the AOP network to other related AOs.

Domain of Applicability

Addressess the relevant biological domain(s) of applicability in terms of sex, life-stage, taxa, and other aspects of biological context. More help

Theoretically, this AOP is relevant to any cell type in any organism at any life stage. Regardless of the type of cell or organism, DNA is susceptible to oxidative damage and repair mechanisms exist to protect the cell against permanent chromosomal damage. Generally, DNA repair pathways are highly conserved among eukaryotic organisms (Wirth et al., 2016). Base excision repair (BER), the primary repair mechanism for oxidative DNA lesions, and associated glycosylases are highly conserved across eukaryotes (Jacobs and Schar, 2012). DNA strand break repair pathways such as homologous recombination (HR) and non-homologous end joining (NHEJ) are shared among eukaryotes as well. Induction of chromosomal aberrations and mutations following oxidative DNA damage has been studied in both eukaryotic and prokaryotic cells. Notably, the KEs of this AOP have been measured in rodent models (i.e., rat and mouse) and mammalian cells in culture (e.g., TK6 human lymphoblastoid cells, HepG2 human hepatic cells, Chinese hamster ovary cells) (Klungland et al., 1999; Arai et al., 2002; Platel et al., 2009; Platel et al., 2011; Deferme et al., 2013).

The occurrence of oxidative DNA damage and chromosomal aberrations are well-established events in humans. Micronucleus and 8-oxodG have been quantified in various tissues and fluids as part of occupational health and biomonitoring studies. Detection of 8-oxodG is typically used as a measure of oxidiative DNA damage to link exposure and/or diseases to oxidative stress [e.g., urinary 8-oxodG (Hanchi et al., 2017); 8-oxodG in tumour samples (Mazlumoglu et al., 2017)]. Micronuclei (MN) are also regularly quantified as a biomarker of genotoxicant exposure or genotoxic stress in humans. Numerous examples of detecting MN in different human tissues (e.g., lymphocytes, buccal cells, urothelial cells) are available in the current literature (Li et al., 2014; Dong et al., 2019; Alpire et al., 2019). Mutations also have been measured in human samples of diverse cell types (Ojha et al., 2018; Zhu et al., 2019; Liljedahl et al., 2019). As such, observations of the MIE and the two AOs of this AOP have been extensively documented in humans.

Essentiality of the Key Events

The essentiality of KEs can only be assessed relative to the impact of manipulation of a given KE (e.g., experimentally blocking or exacerbating the event) on the downstream sequence of KEs defined for the AOP. Consequently, evidence supporting essentiality is assembled on the AOP page, rather than on the independent KE pages that are meant to stand-alone as modular units without reference to other KEs in the sequence. The nature of experimental evidence that is relevant to assessing essentiality relates to the impact on downstream KEs and the AO if upstream KEs are prevented or modified. This includes: Direct evidence: directly measured experimental support that blocking or preventing a KE prevents or impacts downstream KEs in the pathway in the expected fashion. Indirect evidence: evidence that modulation or attenuation in the magnitude of impact on a specific KE (increased effect or decreased effect) is associated with corresponding changes (increases or decreases) in the magnitude or frequency of one or more downstream KEs. More help

A large number of studies have been published that explore the effects of KE modulation on downstream effects. These studies broadly provide strong support to the essentiality of the events within the AOP. Below are examples demonstrating the effects of KE modulation on downstream events.

Essentiality of Increase, oxidative DNA damage (MIE)

  • GSH depletion increases 8-oxo-dG (MIE), and DNA strand breaks (KE2)
    • HepG2 human hepatocytes were treated with 1 mM buthionine sulphoximine (BSO), a GSH-depleting agent, for 4, 8, and 24 hours. Time-dependent statistically significant reduction in GSH was observed at all time points when compared to baseline. The level of 8-oxo-dG lesions was measured 6 and 24 hours after BSO exposure and, at both time points, there was a statistically significant increase in oxidative DNA lesions. A higher magnitude of lesions were present at 24 hours and with statistically significant increases in strand breaks (measured via comet assay) as compared to control (p<0.01) (Beddowes et al., 2003).
  • Antioxidant treatment reduces oxidative lesions, downstream strand breaks, and MN induction (AO2)
    • A 3 hour exposure of HepG2 cells to increasing concentrations of tetrachlorohydroquinone (TCHQ) with N-acetylcysteine (NAC: a radical scanvenger and precursor to glutathione) pre-treatment reduced the amount of cellular ROS (measured by DCFH-DA assay), 8-oxodG, and strand breaks induced by TCHQ measured immediately following exposure. The MN assay at 24 hours indicated a statistically significant decrease in MN at the highest concentration (Dong et al., 2014).
    • Reduction of 8-oxo-dG levels following NAC treatment was also observed in embryos isolated from C57BL/6Jpun/pun mice treated with NAC via drinking water; NAC significantly reduced the number of 8-oxo-dG in the treatment group (Reliene et al., 2004). In human blood mononuclear cells collected in clinical studies, 72-hour NAC treatment significantly reduced the number of MN in the cells. Together, these data support the correlation between the levels of ROS, 8-oxo-dG, and MN frequency (Federici et al., 2015).

Essentiality of Inadequate DNA repair (KE1)

  • The effect of inadequate DNA repair on lesion accumulation and strand breaks (KE2)
    • Nth1 knock-out in vivo - FapyG and FapyA lesions were measured in liver nuclear extracts from wild type and Nth1-/- mice. Statistically significant increases in FapyG and FapyA were observed in Nth1-/- mice. These results demonstrate insufficient repair leading to accumulation of unrepaired oxidative lesions (Hu et al., 2005).
    • Ogg1 knock-out in vitro - In Ogg1-/- mouse embryonic fibroblasts (MEF) treated with 400 µM hydrogen peroxide for 30 minutes, there were significantly fewer strand breaks measured by alkaline comet assay, compared to Ogg1+/+ MEFs. Time series (5 – 90 minutes) immunoblotting of the genomic DNA using anti-8-oxo-dG antibodies indicated a larger magnitude of oxidative lesions in Ogg1-/- cells compared to wild type.  Overall, these results demonstrate the role of Ogg1 in the generation of strand breaks during BER following oxidative DNA damage (Wang et al., 2018).
  • The effect of inadequate DNA repair on MN induction (AO2)
    • Ogg1 knock-out in vivo - In Ogg1-deficient mice exposed to silver nanoparticles (AgNPs) for seven days, a significant increase (compared to Ogg1+/+) in double strand breaks (indicated by % γ-H2AX positive cells) and 8-oxo-dG lesions were observed at the end of treatment and after 7 days of recovery. The magnitude of increase in DSBs after the 7-day recovery was smaller in wild type. Levels of MN were measured in erythrocytes at the same time points. Increases in MN frequency were significant in wild type (compared to untreated control) on day 7, but not after 7 and 14 days of recovery. In Ogg1-/- mice, the increase in MN was significantly higher on day 7 compared to Ogg1+/+ mice and untreated Ogg1-/- mice and remained significant 7 and 14 days after the exposure (Nallanthighal et al., 2017). Thus, the DNA damage was retained in repair deficient mice leading to persistent clastogenic effects.
  • The effect of inadequate DNA repair on mutations (AO1)
    • Suzuki et al. (2010) knocked-down BER-initiating glycosylases (OGG1, NEIL1, MYH, NTH1) in HEK293T human embryonic kidney cells transfected with plasmids that were either positive or negative for 8-oxodG. The resulting changes in mutant frequencies were measured. Compared to the negative control, all knock-downs caused the mutant frequency to increase in 8-oxodG plasmid-containing cells. Moreover, G:C to T:A transversion frequency increased in all analyzed cells. MYH knock-down decreased A:T to C:G transversion frequency of A paired to 8-oxo-dG; the latter result supports the futile MYH-initiated BER model for the repair of 8-oxo-dG opposite A (Suzuki et al., 2010). Overall, these findings support the essential role of DNA repair in mitigating the mutagenic effects of oxidative DNA lesions.

Essentiality of Increase, DNA strand breaks (KE2)

  • Double strand breaks leading to mutations (AO1)
    • Tatsumi-Miyajima et al. (1993) analyzed different mutations arising from the repair of DSBs induced by a restriction endonuclease, AvaI, in five different human fibroblast cell lines transfected with plasmids containing the AvaI restriction site in the supF gene. Cells containing non-digested plasmids (negative control) produced spontaneous supF mutation frequencies between 0.197 and 2.49 x10-3. In cells containing Ava1-digested plasmids, the number of supF mutants increased, indicated by the rejoining fidelity ((total colonies-supF mutants)/total colonies) between 0.50-0.86. Hence, up to 50% of the colonies were mutated at the AvaI restriction site due to erroneous repair of DSBs induced by the endonuclease.(Tatsumi-Miyajima et al., 1993).
  • Reduction in strand breaks leads to decreases in MN frequency (AO2)
    • Differentiated rat thyroid cells (PCCL3) were internally irradiated by 131I treatment and externally irradiated by 5 Gy X-rays, with or without NAC pre-treatment. Cellular ROS and strand breaks were measured at different time points after irradiation. NAC pre-treatment abrogated ROS induced by both internal and external irradiation at 30 min. The level of ROS was also significantly lower in the NAC-treated cells compared to the non-treated cells at later time points (2, 24, and 48 hours). Moreover, the induction of strand breaks at 30 min was also prevented by NAC pre-treatment and there was a reduction in strand breaks compared to the non-treated cells at later time points as well. Finally, the induction of MN measured 24 and 48 hours after irradiation was significantly lower in NAC-treated cells compared to non-treated cells (Kurashige et al., 2017).

Evidence Assessment

Addressess the biological plausibility, empirical support, and quantitative understanding from each KER in an AOP. More help

1. Support for biological plausibility

Defining Question

High (Strong)

Moderate

Low (Weak)

Is there a mechanistic relationship between KEup and KEdown consistent with established biological knowledge?

Extensive understanding of the KER based on extensive previous documentation and broad acceptance.

KER is plausible based on analogy to accepted biological relationships, but scientific understanding is incomplete

Empirical support for association between

KEs, but the structural or functional relationship between them is not understood.

MIE → KE1: Increase, oxidative DNA damage leads to inadequate repair

STRONG

The repair mechanisms for oxidative DNA damage have been extensively studied and are well-understood. It is generally accepted that limits exist on the amount of oxidative DNA damage that can be managed by these repair mechanisms.

KE1 → KE2: Inadequate repair leads to Increase, DNA strand breaks

STRONG

It is well-established that failed attempts to repair of accumulated oxidative lesions and replication fork stalling by both unrepaired and incompletely repaired DNA lesions (e.g., repair intermediates such as abasic sites and SSBs) lead to increase in DNA strand breaks.

KE2 →KE1:

Increase, DNA strand breaks leads to Inadequate repair

STRONG

It is well recognized that the pathways involved in the repair of DSBs is error-prone. In addition to errors induced by NHEJ, all repair mechanisms have a capacity limit; if the number of strand breaks exceed the repair capacity of the cell, unrepaired  SSBs and DSBs may accumulate.

KE1 → AO1: Inadequate repair leads to Increase, mutations

STRONG

Numerous studies (cell-based and in vivo) have demonstrated increases in mutation due to unrepaired oxidative DNA lesions (insufficient repair) and incorrect repair (e.g., non-homologous end joining and error-prone lesion bypass). The mechanisms by which these events occur are well-understood.

KE1 → AO2: Inadequate repair leads to Increase, chromosomal aberrations

STRONG

Chromosomal aberrations may result if DNA repair is inadequate, meaning that the DSBs are misrepaired or not repaired at all. A large variety of different chromosomal aberrations can occur, depending on the timing (i.e., cell cycle) and type of inadequate repair. Examples include copy number variants, deletions, translocations, inversions, dicentric chromosomes, nucleoplasmic bridges, nuclear buds, micronuclei, centric rings, and acentric fragments. A multitude of publications are available that provide details on how these various chromosomal aberrations are formed in the context of inadequate repair.

Non-adjacent:

KE2 →AO1: Increase, DNA strand breaks leads to Increase, mutations

STRONG

Mechanisms of DNA strand break repair have been extensively studied. It is accepted that non-homologous end joining of DSBs can introduce deletions, insertions, translocations, or base substitution.

Non-adjacent

MIE → KE2: Oxidative DNA lesions leads to Increase, DNA strand breaks

MODERATE

Increase in strand breaks due to failed repair of oxidative DNA lesions is an accepted mechanism for the clastogenic effects of oxidative damage. Concurrent increases in the two KEs have been observed in previous studies. However, data that demonstrate a causal relationship, in accordance with the Bradford-Hill criteria for causality, are limited.

Non-adjacent

MIE → AO1: Oxidative DNA lesions leads to Increase, mutations

STRONG

Strong empirical evidence exists in literature demonstrating increases in mutation frequency due to increase in oxidative DNA lesions. Notably, mutagenicity of 8-oxodG, the most abundant oxidative DNA lesion, has been extensively studied and is well-known to cause G to T transversions.

Non-adjacent

KE2→AO2:

Increase, DNA strand breaks leads to Increase, chromosomal aberrations

STRONG

DNA strands breaks must occur for chromosomal aberrations to occur. Increase in strand breaks, especially DSBs, may increase the risk of inadequate repair (lack of repair or misrepair) of the damage, leading to translocations, inversions, insertions, and deletions.

2. Support for Essentiality of KEs

Defining Question

High (Strong)

Moderate

Low (Weak)

Are downstream KEs and/or the AO prevented if an upstream KE is blocked?

Direct evidence from specifically designed experimental studies illustrating essentiality for at least one of the important KEs

Indirect evidence that sufficient modification of an expected modulating factor attenuates or augments a KE

No or contradictory experimental evidence of the essentiality of any of the KEs.

MIE: Increase, oxidative DNA damage

MODERATE

Studies have demonstrated that indirectly reducing or increasing the amount of oxidative DNA lesions by modulating cellular ROS levels (via antioxidant addition or depletion) causes concordant changes in the levels of strand breaks and MN.

KE1: Inadequate repair

STRONG

Numerous studies have investigated inadequate BER of oxidative DNA lesions by disrupting BER through generating gene KO rodent or mammalian cell models. Modulation of the downstream KEs (i.e., DNA strand breaks, mutation, MN induction) by dysfunctional BER has been demonstrated in these studies.

KE2: DNA strand breaks

MODERATE

Theoretically, chromosomal aberrations (AO2) cannot occur unless DNA strand breaks occur. Predominantly, indirect evidence exists that support the essentiality of KE2 in leading to mutations (AO1).

3. Empirical Support for KERs

Defining Question

High (Strong)

Moderate

Low (Weak)

Does empirical evidence support that a change in KEup leads to an appropriate change in KEdown?

Does KEup occur at lower doses and earlier time points than KE down and is the incidence of KEup> than that for KEdown?

Inconsistencies?

Multiple studies showing dependent change in both events following exposure to a wide range of specific stressors.

No or few critical data gaps or conflicting data

Demonstrated dependent change in both events following exposure to a small number of stressors.

Some inconsistencies with expected pattern that can be explained by various factors.

Limited or no studies reporting dependent change in both events following exposure to a specific stressor; and/or significant inconsistencies in empirical support across taxa and species that don’t align with hypothesized AOP

MIE → KE1: Increase, oxidative DNA damage leads to inadequate repair

MODERATE

Empirical in vitro and in vivo data demonstrate that increases in oxidative DNA lesions leads to indications of inadequate repair (i.e., increases in mutation, retention of adducts, increases in lesions despite upregulation of repair enzymes).

KE1 → KE2: Inadequate repair leads to Increase, DNA strand breaks

MODERATE

Limited in vivo data are available. A few In vitro studies have demonstrated a larger increase in DNA strand breaks in BER-defective cells compared to wildtype cells, following various oxidative stresse-inducing chemical exposures.

In certain cases, as demonstrated by Wang et al. (2018), knock-down of OGG1 (BER-initiating glycosylase) reduced the amount of  DNA strand breaks that formed after exposure to hydrogen peroxide - mostly likely due to the reduction in the incidences of incomplete repair. As such, deficiency in different DNA repair proteins can have varying effects on downstream strand breaks; inadequate repair may manifest differently for different stressors.

KE2 →KE1:

Increase, DNA strand breaks leads to Inadequate repair

MODERATE

Results from many studies indicate dose/incidence and temporal concordance between the frequency of DSBs and the rate of inadequate repair. As DNA damage accumulates in cells, the incidence of inadequate DNA repair activity (in the form of non-repaired or misrepaired DSBs) also increases.

Uncertainties in this KER include controversy surrounding the error rate of NHEJ, differences in responses depending on genotoxicant exposure levels and confounding clinical factors (such as smoking) that affect DSB repair fidelity.

KE1 → AO1: Inadequate repair leads to Increase, mutations

STRONG

Repair deficiency causing increases in mutations has been extensively demonstrated in both in vitro and in vivo. Overexpression of repair enzymes has been shown to reduce mutation frequency following chemical exposure in vitro, which further supports the causal relationship between these two KEs.

KE1 → AO2: Inadequate repair leads to Increase, chromosomal aberrations

MODERATE

There is little empirical evidence available that directly examines the dose and incidence concordance between DNA repair and CAs within the same study. Similarly, there is not clear evidence of a temporal concordance between these two events. More research is required to establish empirical evidence for this KER.

Non-adjacent:

KE2 →AO1: Increase, DNA strand breaks leads to Increase, mutations

MODERATE

Evidence from in vitro and in vivo studies demonstrating dose and temporal concordance of the two KEs are available. These investigations utilized various stressors such as chemicals and ionizing radiation.

Non-adjacent

MIE → KE2: Oxidative DNA lesions leads to Increase, DNA strand breaks

MODERATE

Both in vitro and in vivo data are available that the demonstrate dose-response concordance of oxidative DNA lesions formation and strand breakage following exposure to various stressors. However, the temporal concordance between the KEs is not strong; there are discrepancies in the temporal sequence of events that appear to be dependent on the endpoint used to measure the KE (i.e., Fpg comet assay vs. 8-oxodG immunodetection, comet assay vs. ɣ-H2AX immunodetection).

Non-adjacent

MIE → AO1: Increase, oxidative DNA lesions leads to Increase, mutations

STRONG

This KER was demonstrated by knocking out oxidative DNA damage repair protein (OGG1) and exposure to different ROS-inducing chemicals in vitro and in vivo. It is clear that an increase in oxidative DNA lesions is followed by an increase in mutant frequency or G to T transversions.

Non-adjacent

KE2→AO2:

Increase, DNA strand breaks leads to Increase, chromosomal aberrations

MODERATE

Temporal concordance is clear in both in vitro and in vivo data. However, due to the differences in the methods used to measure strand breaks and chromosomal aberrations, the concentration-response of these events often appear to be discordant.

Please also refer to AOP #272 “ Direct deposition of ionizing energy onto DNA leading to lung cancer”, which shares numerous KE and KERs.

Known Modulating Factors

Modulating factors (MFs) may alter the shape of the response-response function that describes the quantitative relationship between two KES, thus having an impact on the progression of the pathway or the severity of the AO.The evidence supporting the influence of various modulating factors is assembled within the individual KERs. More help
Modulating Factor (MF) Influence or Outcome KER(s) involved


Quantitative Understanding

Optional field to provide quantitative weight of evidence descriptors.  More help

The quantitative understanding of the KERs in this AOP is overall weak. Different cell types have different baseline levels of antioxidants and antioxidant enzymes, as well as different oxidative DNA lesion repair capacity. For example, Nishioka et al. (1999) demonstrated difference in the expression level of OGG1 mRNA across different human tissues (Nishioka et al., 1999). Thus, the quantity of oxidative DNA lesions required to overwhelm the repair mechanisms and lead to chromosomal damage or mutations differ by cell type. Furthermore, antioxidant and DNA repair capacities differ by individual in vivo and are influenced by factors such as age and the disease state of the individual; for example, DNA repair ability and antioxidant enzyme activities are known to decline with age in humans (Liguori et al., 2018; Kozakiewicz et al., 2019; Chen et al., 2020). Such are modulating factors for the AOP progression. Thus, we note that different thresholds exist for the amount of oxidative DNA damage that leads to the AO, depending on the individual and the modulating factors affecting the individual.

Modulating Factors

As discussed above, there are various modulating factors for this AOP, including genetic polymorphisms in DNA repair and antioxidant response-associated genes in individuals and the metabolic competency (i.e., phase 2 xenobiotic metabolism) of the cell line used. For in vitro experiments, a critical consideration is the  concentration at which genomic effects are measured, as ROS production is expected to be highly elevated at overtly cytotoxic concentrations (i.e., generally >50% cytotoxicity in the context of genotoxicity testing). Mutations and chromosomal aberrations occurring above certain levels of cytotoxicity are not considered relevant to in vivo outcomes. As such, in vitro genotoxicity testing guidelines should be consulted for specific recommendations for selecting the top chemical exposure concentrations.

Considerations for Potential Applications of the AOP (optional)

Addressess potential applications of an AOP to support regulatory decision-making.This may include, for example, possible utility for test guideline development or refinement, development of integrated testing and assessment approaches, development of (Q)SARs / or chemical profilers to facilitate the grouping of chemicals for subsequent read-across, screening level hazard assessments or even risk assessment. More help

Genotoxicity testing is a fundamental requirement for all chemical and pharmaceutical safety assessments. Although there are established guidelines for in vitro tests, the current standard in vitro genotoxicity assays provide limited mechanistic information and suffer from high sensitivity and low specificity, potentially leading to unnecessary follow up work. The field is moving towards the use of more  biologically relevant in vitro models and tests that inform on mechanisms that cause the observed apical outcome (Whitwell et al., 2015). There is also a movement away from the notion that genotoxicity testing is only valuable to inform potential hazards and identify genotoxic mechanisms of carcinogenesis, as many mechanisms of genotoxicity only operate once a critical exposure threshold is satisfied. Indeed, there is increasing use of genotoxicity data in deriving points of departure to inform risk assessments (Klapacz and Gollapudi, 2020; Luijten et al., 2020; White et al., 2020). Overall, understanding the biological mechanisms (i.e., the MIEs and KEs) that lead to genotoxic outcomes is essential to the risk assessment process (Dearfield et al., 2017), especially if the mechanism is not biologically active at clinically relevant exposures . This AOP network provides a framework for assembling information from different mechanism-based tests to determine the probability that an agent induces oxidative DNA damage, which can be used to demonstrate that the agent itself is not DNA reactive. For example, analysis of a chemical using the Bradford-Hill criteria aligned against this AOP network could be used to determine if the chemical’s primary mode of action is via ROS-induction, rather than an artefact of over-exposure (e.g., cytotoxicity). In the case of a true ROS-driven mechanism, levels of oxidative DNA damage and likely cell cycle delay should occur at concentrations below those that induce chromosomal aberrations and mutations.

Oxidative DNA damage is a long established mechanism of inducing genotoxicity and, thus, a useful endpoint in assessing genotoxicity risk. From a human health perspective, there is an increasing understanding (and acceptance) of the fact that genomic damage such as mutations, in and of themselves, are adverse (e.g., germ cell mutations) (Heflich et al., 2020). However, a chemical that induces oxidative DNA damage will demonstrate a threshold concentration, below which it does not induce measurable genotoxicity. This is due to the various pathways of endogenous DNA repair and enzymatic reductions that prevent progression of oxidative lesions to adverse genotoxicity outcomes, facilitating quantification of safe permissible exposures. Hence, once it is demonstrated for a chemical that this AOP is operable, a quantitative assessment of in vivo genotoxicity data (e.g., micronuclei or mutations) could be used to assess risk, provided the study design is appropriate (White and Johnson, 2016; Dearfield et al., 2017; White et al., 2020).

Overall, AOP networks (such as this one) can inform how different testing methods, including fit-for-purpose mechanistic assays, should be used to quantitatively relate KEs to specific adverse genotoxic outcomes. Presently, this AOP network documents clear gaps in the quantitative understanding of genomic damage induced by oxidative DNA lesions that when filled, will enhance risk assessment and predictive toxicology for chemicals that induce oxidative DNA lesions. In conclusion, AOPs like this can be applied in regulatory assessment of chemicals to (a) facilitate mode of action analysis of chemicals to hypothesize potential molecular initiating events; (b) identify test methods and strategies for use with untested chemicals to link them to the appropriate AOP(s); (c) highlight knowledge gaps and uncertainties in genotoxic MOAs; (d) facilitate the development of new ‘all-in-one’ testing strategies, where MOA and apical endpoints are measured concomitantly; and (e) support a non-linear risk assessment when direct DNA-reactivity is not empirically supported.

References

List of the literature that was cited for this AOP. More help

Alpire, M., C. Cardoso, C. Seabra Pereira, and D. Ribeiro (2019), "Genomic instability in Buccal mucosal cells of children living in abnormal conditions from Santos-Sao Vicente Estuary", Int J Environ Health Res, 1:1-7.

Arai, T., V.P. Kelly, O. Minowa, T. Noda, and S. Nishimura (2002), "High accumulation of oxidative DNA damage, 8-hydroxyguanine, in Mmh/Ogg1 deficient mice by chronic oxidative stress", Carcinogenesis, 23:2005-2010.

Ataseven, N., C. Yuzbasioglu A., and F. Unal (2016), "Genotoxicity of monosodium glutamate", Food Chem Toxicol, 91:8-18.

Ba, X., and I. Boldogh (2018), "8-Oxoguanine DNA glycosylase 1: Beyond repair of the oxidatively modified base lesions", Redox Biol,14:669-678. .

Ballmaier, D. and B. Epe (2006), "DNA damage by bromate: Mechanism and consequences", Toxicol, 221:166-171.

Barnes R., E. Fouquerel, and P. Opresko (2019), "The impact of oxidative DNA damage and stress on telomere homeostasis", Mech Ageing Dev, 177: 37–45.

Beddowes, E., S. Faux, and J.K. Chipman (2003), "Chloroform, carbon tetrachloride and glutathione depletion induce secondary genotoxicity in liver cells via oxidative stress", Toxicol, 187:101-115.

Benbrook, C.M. (2019), "How did the US EPA and IARC reach diametrically opposed conclusions on the genotoxicity of glyphosate-based herbicides?", Envrion Sci Eur, 31:2.

Berquist, B. and D. Wilson III (2012), "Pathways for Repairing and Tolerating the Spectrum of Oxidative DNA Lesions", Cancer Lett, 327:61-72.

Bordin, D. L., Lirussi, L., and H. Nilsen (2021), "Cellular response to endogenous DNA damage: DNA base modifications in gene expression regulation", DNA Repair (Amst), 99:103051.

Bolzan, A. D. (2012), "Chromosomal aberrations involving telomeres and interstitial telomeric sequences", Mutagenesis, 27: 1-15.

Brandsma, I. and D. C. van Gent (2012), "Pathway choice in DNA double strand break repair: observations of a balancing act", Genome Integr, 3:9.

Cadet, J. and J.R. Wagner (2013), "DNA Base Damage by Reactive Oxygen Species, Oxidizing Agents, and UV Radiation", Cold Spring Harb Perspect Biol, 5:a012559.

Caglayan M, J. K. Horton, D. P. Dai ,  D. F. Stefanick, and S. H. Wilson. (2017). "Oxidized nucleotide insertion by pol β confounds ligation during base excision repair". Nature Communications 8.

Cannan, W. J. and D. S. Pederson (2017), "Mechanisms and Consequences of Double-strand DNA Break Formation in Chromatin", J Cell Physiol, 231:3-14.

Ceccaldi, R., B. Rondinelli, and A.D. D'Andrea (2016), "Repair Pathway Choices and Consequences at the Double-Strand Break", Trends Cell Biol, 26:52-64.

Cha, M., D. G. Kim, and I. Mook-Jung. (2015). "The role of mitochondrial DNA mutation on neurodegenerative diseases". Exp Mol Med 47:e150.

Chen Y, A. Geng, W. Zhang, Z. Qian, X. Wan , Y. Jiang, and Z. Mao (2020), "Fight to the bitter end: DNA repair and aging", Ageing Res Rev, 64:101154.

Colussi, C., E. Parlanti, P. Degan, M. Crescenzi, E. Dogliotti, and M. Bignami (2002). "The Mammalian Mismatch Repair Pathway Removes DNA 8-oxodGMP Incorporated from the Oxidized dNTP Pool". Curr Biol 12:912-918.

Cooke, M., M. Evans, M. Dizdaroglu, and J. Lunec (2003), "Oxidative DNA damage: mechanisms, mutation, and disease", FASEB J, 17:1195-1214.

Coquerelle, T., J. Dosch, and B. Kaina (1995), "Overexpression of N-methylpurine-DNA glycosylase in Chinese hamster ovary cells renders them more sensitive to the production of chromosomal aberrations by methylating agents - a case of imbalanced DNA repair ", Mutat Res, 336:9-17.

Dan Dunn, J., L. A. Alvarez, X. Zhang, and T. Soldati (2015), "Reactive oxygen species and mitochondria: A nexus of cellular homeostasis", Redox biol, 6: 472–485.

Dearfield, K., B. Gollapudi, J. Bemis, R. Benz, G. Douglas, R. Elespuru, G. Johnson, D. Kirkland, M. LeBaron, A. Li, F. Marchetti, L. Pottenger, E. Rorije, J. Tanir, V. Thybaud, J. van Benthem, C.L. Yauk, E. Zeiger, and M. Luijten (2017), "Next Generation Testing Strategy for Assessment of Genomic Damage: A conceptual framework and considerations", Environ Mol Mutagen, 58:264-283.

Deavall, D., E. Martin, J. Hornet, and R. Roberts (2012), "Drug-Induced Oxidative Stress and Toxicity", J Toxicol, 2012:645460.

Deferme, L., J.J. Briede, S.M. Claessen, D.G. Jennen, R. Cavill, and J.C. Kleinjans (2013), "Time series analysis of oxidative stress response patterns in HepG2: A toxicogenomics approach  ", Toxicol, 306:24-34.

Dong, H., D. Xu, L. Hu, L. Li, E. Song, and Y. Song (2014), "Evaluation of N-acetyl-cysteine against tetrachlorobenzoquinoneinduced genotoxicity and oxidative stress in HepG2 cells", Food Chem Toxicol, 64:291-297.

Dong, J., J. Wang, Q. Qian, G. Li, D. Yang, and C. Jiang (2019), "Micronucleus assay for monitoring the genotoxic effects of arsenic in human populations: A systematic review of the literature and meta-analysis", Mutat Res, 780:1-10.

Durante, M., J.S. Bedford, D.J. Chen, S. Conrad, M.N. Cornforth, A.T. Natarajan, D. van Gent, and G. Obe (2013), "From DNA damage to chromosome aberrations: Joining the break", Mutat Res, 756:5-13.

Ensminger, M., L. Iloff, C. Ebel, T. Nikolova, B. Kaina, and M. Lobrich (2014), "DNA breaks and chromosomal aberrations arise when replication meets base excision repair", J Cell Biol, 206:29.

Federici, C., K. Drake, C. Rigelsky, L. McNelly, S. Meade, S. Comhair, S. Erzurum, and M. Aldred (2015), "Increased Mutagen Sensitivity and DNA Damage in Pulmonary Arterial Hypertension", Am J Respir Crit Care Med, 192:219-228.

Fouquerel, E., J. Lormand, A. Bose, H. T. Lee, G. S. Kim, J. Li, Sobol, B. D. Freudenthal, S. Myong, and P. L. Opresko (2016), "Oxidative guanine base damage regulates human telomerase activity", Nat Struct Mol Biol, 23: 1092–1100.

Fouquerel, E., R. P. Barnes, S. Uttam, S. C. Watkins, M. P. Bruchez, and P. L. Opresko (2019), "Targeted and Persistent 8-Oxoguanine Base Damage at Telomeres Promotes Telomere Loss and Crisis", Mol Cell, 75: 117-130.

Fujita, M., H. Sasanuma, K. Yamamoto, H. Harada, A. Kurosawa, N. Adachi, M. Omura, M. Hiraoka, S. Takeda, and K. Hirota (2013), "Interference in DNA Replication Can Cause Mitotic Chromosomal Breakage Unassociated with Double-Strand Breaks", PLoS One, 8:e60043.

Gedik, C., S. Boyle, S. Wood, N. Vaughan, and A.R. Collins (2002), "Oxidative stress in humans: validation of biomarkers of DNA damage", Carcinogenesis, 23:1441-1446.

Guo, C., P. Ding, C. Xie, C. Ye, M. Ye, C. Pan, X. Cao, S. Zhang, and S. Zheng (2017), "Potential application of the oxidative nucleic acid damage biomarkers in detection of diseases", Oncotarget, 8:75767-75777.

Gustafson, H. H., D. Holt-Casper, D. W. Grainger, and H. Ghandehari, (2015), "Nanoparticle Uptake: The Phagocyte Problem", Nano today, 10(4): 487–510.

Hashimoto, K., Y. Tominaga, Y. Nakabeppu, and M. Moriya (2004), "Futile short-patch DNA base excision repair of adenine:8-oxoguanine mispair", Nucleic Acids Res, 32:5928-5934.

Hayashi, H., Y. Tominaga, S. Hirano, A. E. McKenna, Y. Nakabeppu, and Y. Matsumoto (2002), "Replication-associated repair of adenine:8-oxoguanine mispairs by MYH", Curr Biol, 12:335–339.

Heflich R. H., G. E. Johnson, A. Zeller, F. Marchetti, G. R. Douglas, K. L. Witt, B. B. Gollapudi, and P. A. White (2020), "Mutation as a Toxicological Endpoint for Regulatory Decision‐Making", Environ Mol Mutagen 61:34-41.

Hanchi, M., L. Campo, E. Polledri, L. Olgiati, D. Consonni, D. Saidane-Mosbahi, and S. Fustinoni (2017), "Urinary 8-Oxo-7,8-Dihydro-2'-Deoxyguanosine in Tunisian Electric Steel Foundry Workers Exposed to Polycyclic Aromatic Hydrocarbons", Ann Work Expo Health, 61:333-343.

Hu, J., N.C. de Souza-Pinto, K. Haraguchi, B. Hogue, P. Jaruga, M.M. Greenberg, M. Dizdaroglu, and V. Bohr (2005), "Repair of formamidopyrimidines in DNA involves different glycosylases: role of the OGG1, NTH1, and NEIL1 enzymes", J Biol Chem, 280:40544-40551.

Iliakis, G., H. Wang, A.R. Perrault, W. Boecker, B. Rosidi, F. Windhofer, W. Wu, J. Guan, G. Terzoudi, and G. Pantelias (2004), "Mechanisms of DNA double strand break repair and chromosome aberration formation", Cytogenet Genome Res, 104:14-20.

Jena, N. R. and P. C. Mishra. (2012). "Formation of ring-opened and rearranged products of guanine: Mechanisms and biological significance". Free Rad Biol Med 53:81-94.

Kier, L.D. and D. Kirkland (2013), "Review of genotoxicity studies of glyphosate and glyphosate-based formulations", Crit Rev Toxicol, 43:283-315.

Klapacz, J. and B. B. Gollapudi (2020), "Considerations for the Use of Mutation as a Regulatory Endpoint in Risk Assessment", Environ Mol Mutagen 61:84-93.

Klungland, A., I. Rosewell, S. Hollenbach, E. Larsen, G. Daly, B. Epe, E. Seeberg, T. Lindahl, and D. Barnes (1999), "Accumulation of premutagenic DNA lesions in mice defective in removal of oxidative base damage", Proc Natl Acad Sci USA, 96:13300-13305.

Kozakiewicz, M., M. Kornatowski, O. Krzywińska, and K. Kędziora-Kornatowska (2019), "Changes in the blood antioxidant defense of advanced age people", Clin Interv Aging, 14: 763–771.

Kramara, J., B. Osia, and A. Malkova (2018), "Break-Induced Replication: The Where, The Why, and The How", Trends Genet, 34:518-531.

Kurashige, T., M. Shimamura, and Y. Nagayama (2017), "N-Acetyl-l-cysteine protects thyroid cells against DNA damage induced by external and internal irradiation", Radiat Environ Biophys, 56:405-412.

Li, P., Y. Gu, S. Yu, Y. Li, J. Yang, and G. Jia (2014), "Assessing the suitability of 8-OHdG and micronuclei as genotoxic biomarkers in chromate-exposed workers: a cross-sectional study", BMJ Open, 4:e005979.

Liguori, I., G. Russo, F. Curcio, G. Bulli, L. Aran, D. Della-Morte, G. Gargiulo, G. Testa, F. Cacciatore, D. Bonaduce, and P. Abete (2018), "Oxidative stress, aging, and diseases", Clin Interv Aging, 13:757-772.

Liljedahl, E., K. Wahlberg, C. Liden, M. Albin, and K. Broberg (2019), "Genetic variants of filaggrin are associated with occupational dermal exposure and blood DNA alterations in hairdressers", Sci Total Environ, 653:45-54.

Luijten, M., N S. Ball, K. Dearfield, B. B. Gollapudi, G. E. Johnson, F. Madia, L. Peel, S. Pfuhler, R. S. Settivari, W. Ter Burg, P. A. White,  and J. van Benthem (2020), "Utility of a next generation framework for assessment of genomic damage: A case study using the industrial chemical benzene", Environ Mol Mutagen, 61:94-113.

Mao, Z., M. Bozzella, A. Seluanov, and V. Gorbunova (2008a), "Comparison of nonhomologous end joining and homologous recombination in human cells", DNA Repair, 7:1765-1771.

Mao, Z., M. Bozzella, A. Seluanov, and V. Gorbunova (2008b), "DNA repair by nonhomologous end joining and homologous recombination during cell cycle in human cells", Cell Cycle, 7:2902-2906.

Markkanen, E., B. Castrec, G. Villani, and U. Hübscher (2012), "A switch between DNA polymerases δ and λ promotes error-free bypass of 8-oxo-G lesions", Proc Natl Acad Sci USA, 109: 20401–20406.

Markkanen, E. (2017), "Not breathing is not an option: How to deal with oxidative DNA damage", DNA Repair, 59:82-105.

Mazlumoglu, M.R., O. Ozkan, H.H. Alp, E. Ozyildirim, F. Bingol, O. Yoruk, and O. Kuduban (2017), "Measuring Oxidative DNA Damage With 8-Hydroxy-2'-Deoxyguanosine Levels in Patients With Laryngeal Cancer", Ann Otol Rhinol Laryngol, 126:103-109.

Mehta, A. and J. Haber (2014), "Sources of DNA Double-Strand Breaks and Models of Recombinational DNA Repair", Cold Spring Harb Perspect Biol, 6:a016428.

Nakamura T., K. Okabe, S. Hirayama, M. Chirifu, S. Ikemizu, H. Morioka, Y. Nakabeppu and Y. Yamagata (2021), "Structure of the mammalian adenine DNA glycosylase MUTYH: insights into the base excision repair pathway and cancer", Nucleic Acids Res, 49:7154–7163.

Nallanthighal, S., C. Chan, T. Murray, A. Mosier, N. Cady, and R. Reliene (2017), "Differential effects of silver nanoparticles on DNA damage and DNA repair gene expression in Ogg1-deficient and wild type mice", Nanotoxicol, 11:996-1011.

Nemec, A., S. Wallace, and J. Sweasy (2010), "Variant base excision repair proteins: Contributors to genomic instability", Seminars Cancer Biol, 20:320-328.

Obe, G., C. Johannes, and S. Ritter (2010), "The number and not the molecular structure of DNA double-strand breaks is more important for the formation of chromosomal aberrations: A hypothesis", Mutat Res, 701:3-11.

Ojha, J., I. Dyagil, S. Finch, R. Reiss, A. de Smith, S. Gonseth, M. Zhou, H. Hansen, A. Sherborne, J. Nakamura, P. Bracci, N. Gudzenko, M. Hatch, N. Babkina, M.P. Little, V.V. Chumak, K. Walsh, D. Bazyka, J. Wiemels, and L. Zablotska (2018), "Genomic characterization of chronic lymphocytic leukemia (CLL) in radiation-exposed Chornobyl cleanup workers", Environ Health, 17:43.

Oka, S. and Y. Nakabeppu (2011), "DNA glycosylase encoded by MUTYH functions as a molecular switch for programmed cell death under oxidative stress to suppress tumorigenesis", Cancer Sci, 102:677-682.

Ondovcik, S.L., L. Tamblyn, J.P. McPherson, and P. Wells (2012), "Oxoguanine Glycosylase 1 (OGG1) Protects Cells from DNA Double-Strand Break Damage Following Methylmercury (MeHg) Exposure", Toxicol Sci, 128:272-283.

Parke, D. V. (1982), "Mechanisms of chemical toxicity--a unifying hypothesis", Regul Toxicol Pharmacol, 2(4):267-86.

Petersen, S., G. Saretzki, and T. von Zglinicki (1998), "Preferential accumulation of single-stranded regions in telomeres of human fibroblasts", Exp Cell Res, 239:152-60.

Platel, A., F. Nesslany, V. Gervais, and D. Marzin (2009), "Study of oxidative DNA damage in TK6 human lymphoblastoid cells by use of the in vitro micronucleus test: Determination of No-Observed-Effect Levels", Mutat Res, 678:30-37.

Poetsch, A., S. Boulton, and N. Luscombe (2018), "Genomic landscape of oxidative DNA damage and repair reveals regioselective protection from mutagenesis", Genome Biol, 19:215.

Reliene, R., E. Fischer, and R. Schiestl (2004), "Effect of N-Acetyl Cysteine on Oxidative DNA Damage and the Frequency of DNA Deletions in Atm-Deficient Mice", Cancer Res, 64:5148-5153.

Rodgers, K. and M. McVey (2016), "Error-prone repair of DNA double-strand breaks", J Cell Physiol, 231:15-24.

Roszkowski, K., W. Jozwicki, P. Blaszczyk, A. Mucha-Malecka, and A. Siomek (2011), "Oxidative damage DNA: 8-oxoGua and 8-oxodG as molecular markers of cancer", Medical Science Monitor, 17:329-333.

Russo, M. T., M. F. Blasi, F. Chiera, P. Fortini, P. Degan, P. Macpherson, M. Furuichi, Y. Nakabeppu, P. Karran , G. Aquuilina, and M. Bignami. (2004). "The Oxidized Deoxynucleoside Triphosphate Pool Is a Significant Contributor to Genetic Instability in Mismatch Repair-Deficient Cells". Mol Cell Biol 24:465-474.

Saki M, Prakash A. 2017. DNA Damage Related Crosstalk Between the Nucleus and Mitochondria. Free Radic Biol Med 107:216-227.

Sakofsky, C.J., S. Ayyar, A. Deem, W.H. Chung, G. Ira, and A. Malkova (2015), "Translesion Polymerases Drive Microhomology-Mediated Break-Induced Replication Leading to Complex Chromosomal Rearrangements", Mol Cell, 60:860-872.

Sedletska, Y., J.P. Radicella, and E. Sage (2013), "Replication fork collapse is a major cause of the high mutation frequency at three-base lesion clusters", Nucleic Acids Res, 41:9339-9348.

Shah, A., K. Gray, N. Figg, A. Finigan, L. Starks, and M. Bennett (2018), ". Defective Base Excision Repair of Oxidative DNA Damage in Vascular Smooth Muscle Cells Promotes Atherosclerosis", Circulation, 138:1446-1462.

Shih, W., C. Chang, H. Chen, and K. Fan (2018), "Antioxidant activity and leukemia initiation prevention in vitro and in vivo by N‑acetyl‑L‑cysteine", Oncol Lett, 16:2046-2052.

Smith, M.T., K.Z. Guyton, C.F. Gibbons, J.M. Fritz, C.J. Portier, I. Rusyn, D.M. DeMarini, J.C. Caldwell, R.J. Kavlock, P.F. Lambert, S.S. Hecht, J.R. Bucher, B.W. Stewart, R.A. Baan, V.J. Cogliano, and K. Straif. (2016), "Key Characteristics of Carcinogens as a Basis for Organizing Data on Mechanisms of Carcinogenesis", Environ Health Perspect. 2016 Jun;124(6):713-21.

Suzuki, T., H. Harashima, and H. Kamiya (2010), "Effects of base excision repair proteins on mutagenesis by 8-oxo-7,8-dihydroguanine (8-hydroxyguanine) paired with cytosine and adenine", DNA Repair, 9:542-550.

Taggart, D., S. Fredrickson, V. Gadkari, and Z. Suo (2014), "Mutagenic Potential of 8-Oxo-7,8-dihydro-2′-deoxyguanosine Bypass Catalyzed by Human Y-Family DNA Polymerases", Chem Res Toxicol, 27:931-940.

Tatsumi-Miyajima, J., T. Yagi, and H. Takebe (1993), "Analysis of mutations caused by DNA double-strand breaks produced by a restriction enzyme in shuttle vector plasmids propagated in ataxia telangiectasia cells", Mutat Res, 294:317-323.

Tell, G., F. Quadrifoglio, C. Tiribelli, and M.R. Kelley (2009), "The Many Functions of APE1/Ref-1: Not Only a DNA Repair Enzyme", Antioxid Redox Signal, 11:601-619.

Veith, A. and B. Moorthy, (2018), "Role of cytochrome P450s in the generation and metabolism of reactive oxygen species", Curr opin toxicol, 7: 44–51.

Wang, R., C. Li, P. Qiao, Y. Xue, X. Zheng, H. Chen, X. Zeng, W. Liu, I. Boldogh, and X. Ba (2018), "OGG1-initiated base excision repair exacerbates oxidative stress-induced parthanatos", Cell Death and Disease, 9:628.

Whitaker, A., M. Schaich, M.S. Smith, T. Flynn, and B. Freudenthal (2017), "Base excision repair of oxidative DNA damage: from mechanism to disease", Front Biosci, 22:1493-1522.

White, P. A., A. S. Long, and G. E. Johnson  (2020), "Quantitative Interpretation of Genetic Toxicity Dose‐Response Data for Risk Assessment and Regulatory Decision‐Making: Current Status and Emerging Priorities", Environ Mol Mutatgen, 61:66-83.

White, P.A. and G.E. Johnson (2016), "Genetic toxicology at the crossroads-from qualitative hazard evaluation to quantitative risk assessment", Mutagenesis, 31:233-237.

Whitwell, J., R. Smith, K. Jenner, H. Lyon, D. Wood, J. Clements, K. Aschcroft-Hawley, B. B. Gollapudi, D. Kirkland, E. Lorge, S. Pfuhler, J. Tanir, and V. Thybaud (2015), "Relationships between p53 status, apoptosis and induction of micronuclei in different human and mouse cell lines in vitro: implications for improving existing assays", Environ Mutatgen, 789-790:7-27.

Wirth, N., C.N. GrosBuechner, C. Kisker, and I. Tessmer (2016), "Conservation and Divergence in Nucleotide Excision Repair Lesion Recognition", J Biol Chem, 291:18932-18946.

Yang, N., A. Chaudry, and S. Wallace (2006), "Base excision repair by hNTH1 and hOGG1: A two edged sword in the processing of DNA damage in gamma-irradiated human cells", DNA Repair, 5:43-51.

Yang, N., H. Galick, and S. Wallace (2004), "Attempted base excision repair of ionizing radiation damage in human lymphoblastoid cells produces lethal and mutagenic double strand breaks", DNA Repair, 3:1323-1334.

Yu, H., L. Venkatarangan, J. Wishnok, and S. R. Tannenbaum. (2005). "Quantitation of Four Guanine Oxidation Products from Reaction of DNA with Varying Doses of Peroxynitrite". Chem Res Toxicol 18:1849-1857.

Zhu, F., Y. Zhang, L. Shi, C. Wu, S. Chen, H. Zheng, and D. Song (2019), "Gene mutation detection of urinary sediment cells for NMIBC early diagnose and prediction of NMIBC relapse after surgery", Medicine, 98:e16451.
